Description
We adopt advanced technology and select highest-quality components to ensure that our products conform to and adapt to the application requirements industrial-grade lighting. The Trackstar LED tunnel light is specially designed for tunnel lighting.
Standard: IEC60598-1/IEC60068-2/
Certificate: ROHS,CE
Features
1,According to GB8383-2010 explosion-proof to designed and manufactured, work safely in various flammable and explosive places(except coal mines)
2,The compact design optimizes the construction, provides a very cost-efficient product and guarantee the proper performance and durability.
3,The modular structure and the air guide groove back-tilt type to enhance the heat dissipation,which improves the power source span life.
4,Unique design of dual-cavity independent structure ensure that the stable operation of each electronic and realizes the self-cleaning function of the product.
5,The transparent cover is made of imported PC,with high light transmittance and impact resistance.
6,Light source used by 2.0 ultra-high thermal conductivity aluminum, heat and impact resistant tempered glass lens with anti-glare diffuser.
7,The lamp surface adopt the latest spraying technology, it doesn’t change color ,rust, anti-corrosion and anti-static adsorption,ensure long time in the outdoor.
8,The small volume and light weight,cables and wires directly into the wiring and installation is simple and convenient
Basic | |
Product Name | LED Flood Light |
Product Model | Discovery |
Optics | |
Color Temperature | Cold white:5500K-6000K |
Warm white:2700K-3000K | |
Lumen Per Watt | Cold white≥105lm/w |
Warm White≥85lm/w | |
CRI | Cold white:Ra≥70 |
Warm white:Ra≥80 | |
Working Temperature | -40℃-+60℃ |
Power Factor | >0.9 |
Beam Angle | 15°/25°/60°for option |
Electrical | |
Input Voltage | AC100V-AC240V |
Frequency | 50Hz-60Hz |
Rated Power | 120W/160W/200W/240W/320W/ 400W/480W |
Lamp Life | >70000h |
OEM Service | Color temperature/Power/ LED optical angle/Working times |
Mechanics | |
Material | Aluminum alloy |
Safety Wire Material | Stainless steel |
IP Rate | IP66 |
Body Color | Sliver |
